Mitsubishi Evo 10 4B11T Direct Replacement Exhaust Manifold

SKU: 4B11T-EVOX-DR-EX

Mitsubishi Evo 10 4B11T Direct Replacement Exhaust Manifold

SKU: 4B11T-EVOX-DR-EX
Regular price $1,250.00 Sale price $1,225.00 Save $25
/
  • Low stock - 2 items left
  • Inventory on the way

Specifications:

  • Material: SUS347 Stainless Steel Investment Cast Construction

Features:

  • 33mm ID runners.
  • Retains the use of the OEM heat shield (1" Raised) and hardware.
  • Lengthened center 2 runners for a more equal length design.
  • Direct replacement for factory turbo manifold.

Package Contents:

  • Exhaust Manifold

Notes:

  • Turbo Compatibility: Stock Frame Turbochargers
  • Mitsubishi Evo X 2008-2015 (Stock / TD05 frame turbo); OR
  • Mitsubishi Ralliart 2009-2015 (TD05 turbo conversion)
  • Designed in Australia with Lifetime Warranty*

Artec direct replacement cast stainless steel turbo exhaust manifold for TD05 frame turbo for the Mitsubishi Evo X or Ralliart (with TD05 conversion). The factory manifolds are prone to cracking, and most of the aftermarket manifolds available don't provide a solution for thermal management.

Our manifold retains the use of the OEM heat shield, albeit raised up 26mm (1"). The lower heat shield mounts can also be retained if our 4"/3.5" dump / 02 housing is used in combination with our manifold. For the runner design, we have chosen to lengthen the center 2 runners to create a more equal length manifold design. This manifold uses 33mm ID runners to keep the ultra sharp throttle response that the OEM manifold offers.

 --

At ARTEC we have revolutionised the turbo manifold industry with our industry leading SUS347 stainless steel investment cast manifolds.

All of our manifolds are engineered and designed from the ground up, CFD simulated and, most importantly, tested in the real world to achieve maximum flow and heat dispersion. The cast stainless construction allows us to maximise flow and efficiency by having smooth merging angles and eliminating any restrictions from tight radius bends or runners.

The result is a truly optimised manifold with consistent performance, resistant to heat pooling and cracking, plus a beautiful smooth exterior finish.

Designed and tested in Australia, backed with a lifetime warranty.

    Small items: 1-3 Days via Express Post Satchel

    Medium Sized Items: 2-3 working days via AusPost Express or Courier (Depending on location)

    Large Items: 2-8 working days (Large items can only be sent via courier, and delivery time depends on both courier and location

    *Delivery to rural or remote areas, NT, WA, and TAS may take longer*

    Specifications:

    • Material: SUS347 Stainless Steel Investment Cast Construction

    Features:

    • 33mm ID runners.
    • Retains the use of the OEM heat shield (1" Raised) and hardware.
    • Lengthened center 2 runners for a more equal length design.
    • Direct replacement for factory turbo manifold.

    Package Contents:

    • Exhaust Manifold

    Notes:

    • Turbo Compatibility: Stock Frame Turbochargers
    • Mitsubishi Evo X 2008-2015 (Stock / TD05 frame turbo); OR
    • Mitsubishi Ralliart 2009-2015 (TD05 turbo conversion)
    • Designed in Australia with Lifetime Warranty*

    Artec direct replacement cast stainless steel turbo exhaust manifold for TD05 frame turbo for the Mitsubishi Evo X or Ralliart (with TD05 conversion). The factory manifolds are prone to cracking, and most of the aftermarket manifolds available don't provide a solution for thermal management.

    Our manifold retains the use of the OEM heat shield, albeit raised up 26mm (1"). The lower heat shield mounts can also be retained if our 4"/3.5" dump / 02 housing is used in combination with our manifold. For the runner design, we have chosen to lengthen the center 2 runners to create a more equal length manifold design. This manifold uses 33mm ID runners to keep the ultra sharp throttle response that the OEM manifold offers.

     --

    At ARTEC we have revolutionised the turbo manifold industry with our industry leading SUS347 stainless steel investment cast manifolds.

    All of our manifolds are engineered and designed from the ground up, CFD simulated and, most importantly, tested in the real world to achieve maximum flow and heat dispersion. The cast stainless construction allows us to maximise flow and efficiency by having smooth merging angles and eliminating any restrictions from tight radius bends or runners.

    The result is a truly optimised manifold with consistent performance, resistant to heat pooling and cracking, plus a beautiful smooth exterior finish.

    Designed and tested in Australia, backed with a lifetime warranty.
